Presentation
- Go everywhere
- With the best value for money
Specifications
Go everywhere
- High precision driving & smoothness
- Comfort & agility
- Indoor / outdoor rated (versatile)
- Easy access to the platform
- Smart transportability & lifting
With the best value for money
- Haulotte Activ'Energy Management takes care of your batteries
- Smart mast system
- Minimal maintenance & downtime
- Direct electric drive with brushless AC motors
- Easy access to components
- Haulotte Activ'Screen (onboard diagnostic)
| Working height | 5.8 m |
| Platform height | 3.8 m |
| Horizontal outreach | 0.4 m extension (option) |
| Lift capacity - inside | 230 kg (2 pers.) |
| Lift capacity - outside | 230 kg (1 pers.) |
| Platform size | 0.77 x 1.38 m |
| Platform size with extension (option) | 0.77 x 1.30 + 0.4 m |
| Length | 1.4 m |
| Width | 0.79 m |
| Height - stowed | 1.8 m |
| Wheelbase | 1.06 m |
| Ground clearance | 6 cm |
| Drive speed proportional | 0.8 - 4.5 km/h |
| Turning radius - outside | 1.7 m |
| Tilt alarm | 1.5 ° / 3 ° |
| Gradeability | 25 % |
| Max driveable platf. height | 3.8 m |
| Tyres - non marking | 318 x 108 |
| Power source | 24 V - 105 Ah (C5) |
| Weight | 862 kg |
- Haulotte Activ'Energy Management: Smart CAN charger
- 24 V electric drive brushless AC motors
- 2 x 12 V - 105 Ah batteries
- Battery charge indicator
- Haulotte Activ'Screen
- Fork lifting eyes
- Hoisting and lifting eyes
- Swing door entry gate
- Mobile potholes
- 2 front steering wheels
- 2 rear driving wheels
- Non marking tyres
- Brake release
- Travel alarm
- Emergency stop
- Emergency hand pump
- 2 control stations at cage and ground level
- Mobile upper control box
- 2 towing hooks
- Walkable entry plinth
- Overload sensor
- Motion flashing light
- Haulotte Activ'Energy Management: automatic or manual battery waterfilling systems
- Upper control box protection cover
- Tool tray
- Platform extension deck + 0.4 m (height stowed: 1.8 m)
- Power line in platform
- Ground-fault circuit interrupter 30 mA
- Telematics ready
- Biodegradable oil
- Hydraulic oil for cold countries
- Flashing light
- Fluorescent tube caddy
